Anti-fouling screen/anti-silt barrier
|
material |
specification |
|
|
Above water |
PVC |
Height :160mm、gram weight :600g/m2 |
|
Floating body |
EPS polystyrene |
Diameter 16cm*1.1m |
|
Underwater part |
PET needled geotextile |
Depth :0.5-10m、gram weight :200gsm |
|
Counterweight chain |
Hot-dip galvanized iron chain |
Diameter 4mm、1.0kg/m |
|
ribbon |
Polyester wheel |
Width 5cm |
|
join |
Aluminum sheet ASTM/ Polyester rope + flat ribbon |
|
|
Section length (m) |
20 |
Wave height (m) |
|
Wind speed (m/s) |
5 |
Flow rate (kn) |
|
Temperature (℃) |
'-20 to 50 |
Storage temperature (℃) |
material
specification
Above water
PVC
Height :200mm、gram weight :600g/m?
Floating body
EPS polystyrene
Diameter 20cm*1.1m
Underwater part
PET needled geotextile
Depth :0.5-10m、gram weight :300gsm
Counterweight chain
Hot-dip galvanized iron chain
Diameter 6mm、1.5kg/m
ribbon
terylene
Width 5cm
join
Aluminum sheet ASTM/ Polyester rope + flat ribbon
Section length (m)
20
Wave height (m)
Wind speed (m/s)
8
Flow rate (kn)
Temperature (℃)
-20 to 50
Storage temperature (℃)
material
specification
Above water
PVC
Height :300mm、gram weight :800g/m?
Floating body
EPS polystyrene
Diameter 30cm*1.1m
Underwater part
PET needled geotextile
Depth :0.5-10m、gram weight :400gsm
Counterweight chain
Hot-dip galvanized iron chain
Diameter 10mm、2.2kg/m
ribbon
terylene
Width 5cm
join
Aluminum sheet ASTM/ Polyester rope + flat ribbon
Section length (m)
20
Wave height (m)
Wind speed (m/s)
15
Flow rate (kn)
